1. Soaking tank soaking tank is a cylindrical tank with conical bottom. The height diameter ratio of the tank is 2 ∶ 1; The taper of tank bottom shall not be less than 45 °; Each tank is separately equipped with infusion pump and heater. The 100000 ton starch plant is equipped with 8 300m3 tanks, the 30000 ton starch plant is equipped with 8 100m3 tanks, and the 10000 ton starch plant is equipped with 6 40m3 tanks.

2.玉米破碎机 一般采用凸齿磨。

2. Corn crusher generally adopts convex tooth mill.

3.胚芽旋流器 过去老厂多用胚芽分离桶或漂浮槽，而目前都采用旋流器分离胚芽。

3. Germ cyclone used to use germ separation barrel or floating tank in old factories, but now cyclone is used to separate germ.

4.胚芽洗涤曲筛（曲筛又名弧形筛） 万吨级淀粉厂一般用玉米脱水曲筛1台，胚芽洗涤曲筛3台。

4. Germ washing curved screen (curved screen, also known as arc screen) one corn dehydration curved screen and three germ washing curved screens are generally used in 10000 ton starch plants.

5.冲击磨 细磨一般用冲击磨（针磨），比砂盘磨为好。

5. Impact grinding fine grinding generally uses impact grinding (needle grinding), which is better than sand disc grinding.

6.纤维分离洗涤用压力曲筛 老式工艺中还有采用锥形离心筛、振动平筛的，现在基本都采用压力曲筛。

6. Pressure curved screen for fiber separation and washing. In the old process, conical centrifugal screen and vibrating flat screen are also used. Now, pressure curved screen is basically used.

7.淀粉与蛋白分离 老式工艺用沉淀法的流槽工艺，现已淘汰。如今一般都采用碟式喷嘴型分离机，简称淀粉分离机。

7. The old-fashioned process of separating starch and protein, the chute process of precipitation method, has been eliminated. Nowadays, disc nozzle separator is generally used, which is referred to as starch separator for short.

8.淀粉洗涤的旋流分离器 它是由一定数量的φ10mm旋流管组合而成的，因此也称多管旋流器。生产中，通常采用9—12级，多管旋流器分C型、TM型和RC型，国产有72型和50型的，均属于C型系列。

8. The cyclone separator for starch washing consists of a certain number of φ It is composed of 10mm cyclone tubes, so it is also called multi tube cyclone. In production, 9-12 stages are usually used. Multi tube hydrocyclones are divided into C-type, TM type and RC type. Domestic models 72 and 50 belong to C-type series.

9.麸质浓缩分离机 一般都用碟片式喷嘴型分离机。

9. Generally, disc nozzle separator is used for gluten concentration separator.

10.麸质回收 小型厂可用板框压滤机，大型厂一般都用转鼓式真空吸滤机，也有用沉降离心机的。

10. Plate and frame filter presses can be used in small-scale gluten recovery plants, while rotary drum vacuum suction filters and sedimentation centrifuges are generally used in large-scale plants.

11.淀粉干燥 一般都用气流干燥。

11. Starch drying is generally air drying.

12.淀粉脱水 一般用卧式刮刀离心机。

12. Horizontal scraper centrifuge is generally used for starch dehydration.

13.管束式干燥机 湿纤维、胚芽饼和浓缩玉米浆混合后一般采用管束式干燥机干燥。

13. After mixing wet fiber, germ cake and concentrated corn slurry, the tube bundle dryer is generally used for drying.
